SAUNDERS® Tank Outlet
SAUNDERS® Tank Outlet valve incorporates the performance and features of a diaphragm valve into a Machined Block tank outlet design and is designed for use at the bottom of a tank or vessel to drain or sample. The design enhances structural integrity, minimises deadleg and reduces potential for contamination.
Features And Benefits
Technical Details
Applications
Literature
Certificates
Videos
Features And Benefits
- Machined Block construction, free from internal fabrication welds to enhance structural integrity
- Facilitates optimum vessel agitation and prevents any possibility of bacterial entrapment
- Design promotes optimum drainability for vessel sampling
- Compact size envelope reduces internal wetted area and potential for hold up volume
- Flexibility of design allows easy incorporation of integral purge/sample valves
Technical Details
DESIGN FEATURES
- Performance and features of a diaphragm valve incorporated into a Machined Block tank outlet design, utilised at the bottom of a tank or vessel to drain or sample.
- The design enhances structural integrity, minimises deadleg and reduces potential for contamination
MATERIALS OF CONSTRUCTION
- Standard 316L ASTM A-479
- DIN 1.4435, AL6XN, Hastelloy and other materials available on request
SIZE RANGE
- DN8 (0.25”) – DN150 (6.00”)
SPECIAL OPTIONS
- Integral purge and Bio-Block options engineered against customer request
