SAUNDERS® Multi-Port
Saunders® standard Multi Weir Diverters offer a compact, high integrity machined block solution compared with traditional fabricated 2-Way valves clusters, and play a valuable role in achieving optimum process design with reduced internal wetted area.
Features And Benefits
Technical Details
Applications
Literature
Certificates
Videos
Features And Benefits
- Machined Block construction, free from internal fabrication welds to enhance structural integrity
- Minimum deadleg design to reduce risk of process contamination
- Reduced internal wetted area and product contact surface
- Excellent drainage characteristics for effective sterilisation
- Compact size envelope allows flexibility in system design and simplified installation
Technical Details
DESIGN FEATURES
- Multi weir Diverter options are designed to provide zero deadleg orientation when a process line needs to be divided into two or more process streams or when multiple lines are combined into one to reduce intrusion points
MATERIALS OF CONSTRUCTION
- Standard 316L ASTM A-479
- DIN 1.4435, AL6XN, Hastelloy and other materials available on request
SIZE RANGE
- DN8 (0.25”) – DN80 (3.00″), DN150 (6.00”)
SPECIAL OPTIONS
- Custom designs available to address unique piping challenges
